引言

PolarDB Mysql版支持OR子句/IN-List表达式转UNION ALL的查询优化功能，能够在生成计划期间尝试将合适的OR子句/IN-List转换成UNION ALL形式，再进行基于代价的路径选择，得到更优的执行计划。

背景

目前，Mysql优化器对SQL中的OR子句过滤条件的优化能力较为有限。如果OR子句中的过滤条件仅涉及一张表，且所有过滤条件上均具备适当的索引，则优化器会为此类场景生成一个Range Access Path或者Index Merge Access Path。例如：

mysql> desc select c2  from t3 where c2 >98 or c2 <= 1;
+----+-------------+-------+------------+-------+---------------+-----------+---------+------+------+----------+------------------------------------+
| id | select_type | table | partitions | type  | possible_keys | key       | key_len | ref  | rows | filtered | Extra                              |
+----+-------------+-------+------------+-------+---------------+-----------+---------+------+------+----------+------------------------------------+
|  1 | SIMPLE      | t3    | NULL       | range | idx_c2_c3     | idx_c2_c3 | 5       | NULL | 4737 |   100.00 | Using index condition; Using index |
+----+-------------+-------+------------+-------+---------------+-----------+---------+------+------+----------+------------------------------------+
mysql> desc select * from t0 where key1 < 3 or key2 > 1020;
+----+-------------+-------+------------+-------------+---------------+-------+---------+------+------+----------+--------------------------------------+
| id | select_type | table | partitions | type        | possible_keys | key   | key_len | ref  | rows | filtered | Extra                                |
+----+-------------+-------+------------+-------------+---------------+-------+---------+------+------+----------+--------------------------------------+
|  1 | SIMPLE      | t0    | NULL       | index_merge | i1,i2         | i1,i2 | 4,4     | NULL |    3 |   100.00 | Using sort_union(i1,i2); Using where |
+----+-------------+-------+------------+-------------+---------------+-------+---------+------+------+----------+--------------------------------------+

如果OR子句涉及多张表，优化器只能将该OR子句视为连接后的过滤条件，这可能导致SQL执行效率降低。例如：

desc analyze select * from t1,t3 where t3.c1 >98 or t1.b <= 0;
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                                                                                                      |
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Filter: ((t3.c1 > 98) or (t1.b <= 0))  (cost=409669.60 rows=4096000) (actual time=115.259..5416.434 rows=81920 loops=1)
    -> Inner hash join (no condition)  (cost=409669.60 rows=4096000) (actual time=37.843..3556.126 rows=4096000 loops=1)
        -> Table scan on t3  (cost=1.01 rows=6400) (actual time=0.187..433.147 rows=6400 loops=1)
        -> Hash
            -> Table scan on t1  (cost=64.75 rows=640) (actual time=1.216..35.969 rows=640 loops=1)
 |
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (5.44 sec)

上述OR子句被当作一个整体，优化器无法使用t1.b或者t3.c1上的索引，导致t1与t2进行全表扫描。实际上，OR子句在逻辑上可以转化为UNION ALL，包含两个或多个分支的查询形式。例如，上述示例可以改写为：

EXPLAIN ANALYZE
SELECT * FROM t1 ,t3 WHERE  t1.b <= 0
UNION ALL
SELECT * FROM t1,t3  WHERE t3.c1 >98 AND (t1.b >0 OR (t1.b <= 0) IS NULL);
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                                                                                                                   |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Append  (actual time=58.272..302.546 rows=81920 loops=1)
    -> Stream results  (actual time=39.204..39.204 rows=0 loops=1)
        -> Inner hash join (no condition)  (cost=136589.21 rows=1365197) (actual time=39.202..39.202 rows=0 loops=1)
            -> Table scan on t3  (cost=3.02 rows=6400) (never executed)
            -> Hash
                -> Filter: (t1.b <= 0)  (cost=64.75 rows=213) (actual time=39.118..39.118 rows=0 loops=1)
                    -> Table scan on t1  (cost=64.75 rows=640) (actual time=0.322..38.382 rows=640 loops=1)
    -> Stream results  (actual time=19.062..237.913 rows=81920 loops=1)
        -> Inner hash join (no condition)  (cost=8239.26 rows=81920) (actual time=19.053..149.818 rows=81920 loops=1)
            -> Filter: ((t1.b > 0) or ((t1.b <= 0) is null))  (cost=0.51 rows=640) (actual time=0.180..40.371 rows=640 loops=1)
                -> Table scan on t1  (cost=0.51 rows=640) (actual time=0.176..39.572 rows=640 loops=1)
            -> Hash
                -> Index range scan on t3 using idx_c1, with index condition: (t3.c1 > 98)  (cost=46.50 rows=128) (actual time=7.875..18.329 rows=128 loops=1)
 |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.32 sec)

改写后优化器利用t3.c1上的索引，减少中间处理的数据量，从而提高执行性能。 PolarDB Mysql版在生成计划期间，能够尝试将适当的OR子句/IN-List转换为UNION ALL形式，随后基于代价进行路径选择，从而最终获得更优的执行计划。

使用说明

该功能是基于代价自适应应用改写的，如果您的sql估算代价比cbqt_cost_threshold大，优化器就会尝试应用or展开改写，如果改写后执行的更快，优化器将选用改写的方式进行执行，当然您可以通过将参数or_expansion_mode=on来开启该改写功能。设置参数值的具体操作请参见设置集群参数和节点参数。

参数名称	描述
cbqt_cost_threshold	用于控制对SQL尝试进行OR转换的执行计划总代价阈值，如果 SQL 原始的执行计划总代价没有超过阈值，则不会进行OR转换。取值范围：[0, +∞)，默认值为100000。设置参数为0时，表示对任何SQL都尝试进行OR转换。不建议设置为0，可能会让所有SQL计划时间变长，影响性能。
or_expansion_mode	用于控制OR子句/IN-List转换UNION ALL功能的开关，取值如下：● on: ro/rw全开。● off：关闭。● replica_on: 仅ro开启，默认值为replica_on.

改写规则及示例

数据准备

CREATE TABLE `t1` (
  `a` int(11) DEFAULT NULL,
  `b` int(11) DEFAULT NULL,
  KEY `idx_a` (`a`)
) ENGINE=InnoDB;
INSERT INTO `t1` VALUES (1,1),(2,2),(3,3),(4,4),(5,5),(6,6),(7,7),(8,8),(9,9),(10,10);
insert into t1 select * from t1;
insert into t1 select * from t1;
insert into t1 select * from t1;
insert into t1 select * from t1;
insert into t1 select * from t1;
insert into t1 select * from t1;
insert into t1 select * from t1;

CREATE TABLE `t3` (
  `c1` int(11) NOT NULL ,
  `c2` int(11) DEFAULT NULL,
  `c3` int(11) DEFAULT NULL,
  `c4` int(11) DEFAULT NULL,
  KEY idx_c1(`c1`),
  KEY `idx_c2_c3` (`c2`,`c3`)
) ENGINE=InnoDB;

INSERT INTO `t3` VALUES (1,0,1,0),(2,0,2,0),(3,0,3,0),(4,0,4,0),(5,0,5,0),(6,0,6,0),(7,0,7,0),(8,0,8,0),(9,0,9,0),(10,0,10,0),(11,0,11,0),(12,0,12,0),(13,0,13,0),(14,0,14,0),(15,0,15,0),(16,0,16,0),(17,0,17,0),(18,0,18,0),(19,0,19,0),(20,0,20,0),(21,0,21,0),(22,0,22,0),(23,0,23,0),(24,0,24,0),(25,1,25,0),(26,1,26,0),(27,1,27,0),(28,1,28,0),(29,1,29,0),(30,1,30,0),(31,1,31,0),(32,1,32,0),(33,1,33,0),(34,1,34,0),(35,1,35,0),(36,1,36,0),(37,1,37,0),(38,1,38,0),(39,1,39,0),(40,1,40,0),(41,1,41,0),(42,1,42,0),(43,1,43,0),(44,1,44,0),(45,1,45,0),(46,1,46,0),(47,1,47,0),(48,1,48,0),(49,1,49,0),(50,1,50,1),(51,1,51,1),(52,1,52,1),(53,1,53,1),(54,1,54,1),(55,1,55,1),(56,1,56,1),(57,1,57,1),(58,1,58,1),(59,1,59,1),(60,1,60,1),(61,1,61,1),(62,1,62,1),(63,1,63,1),(64,1,64,1),(65,1,65,1),(66,1,66,1),(67,1,67,1),(68,1,68,1),(69,1,69,1),(70,1,70,1),(71,1,71,1),(72,1,72,1),(73,1,73,1),(74,1,74,1),(75,2,75,1),(76,2,76,1),(77,2,77,1),(78,2,78,1),(79,2,79,1),(80,2,80,1),(81,2,81,1),(82,2,82,1),(83,2,83,1),(84,2,84,1),(85,2,85,1),(86,2,86,1),(87,2,87,1),(88,2,88,1),(89,2,89,1),(90,2,90,1),(91,2,91,1),(92,2,92,1),(93,2,93,1),(94,2,94,1),(95,2,95,1),(96,2,96,1),(97,2,97,1),(98,2,98,1),(99,2,99,1),(100,2,100,1);
insert into t3 select * from t3;
insert into t3 select * from t3;
insert into t3 select * from t3;
insert into t3 select * from t3;
insert into t3 select * from t3;
insert into t3 select * from t3;

analyze table t1,t3;

说明：目前该功能在灰度测试中，在ro上默认开启，rw上需要额外设置

set or_expansion_mode=on

规则一：OR子句转换为UNION ALL功能

set cbqt_cost_threshold=1;
set polar_optimizer_switch='or_expansion=on';

mysql> desc select * from t1,t3 where t3.c1 >98 or t1.a<5;
+----+-------------+-------+------------+-------+---------------+--------+---------+------+------+----------+--------------------------------------------+
| id | select_type | table | partitions | type  | possible_keys | key    | key_len | ref  | rows | filtered | Extra                                      |
+----+-------------+-------+------------+-------+---------------+--------+---------+------+------+----------+--------------------------------------------+
|  1 | PRIMARY     | t1    | NULL       | range | idx_a         | idx_a  | 5       | NULL |  256 |   100.00 | Using index condition; Using MRR           |
|  1 | PRIMARY     | t3    | NULL       | ALL   | NULL          | NULL   | NULL    | NULL | 6400 |   100.00 | Using join buffer (hash join)              |
|  2 | UNION       | t3    | NULL       | range | idx_c1        | idx_c1 | 4       | NULL |  128 |   100.00 | Using index condition; Using MRR           |
|  2 | UNION       | t1    | NULL       | ALL   | NULL          | NULL   | NULL    | NULL |  640 |    66.67 | Using where; Using join buffer (hash join) |
+----+-------------+-------+------------+-------+---------------+--------+---------+------+------+----------+--------------------------------------------+

综上，开启OR子句转UNION ALL功能后，执行计划中可以利用t1.a和t3.c1上的索引，达到和手动改写成UNION ALL相同的效果。

规则二：TOP-K类型 OR子句转换为UNION ALL功能

 #######先关闭改写，看下原生耗时
 set polar_optimizer_switch='or_expansion=off';
  mysql> desc analyze  select c2 from t3 where (c2 = 2 or c2= 0 )  ORDER BY `t3`.`c3` DESC LIMIT 5;
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                                                                                                                                                                                             |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Limit: 5 row(s)  (actual time=193.389..193.393 rows=5 loops=1)
    -> Sort: t3.c3 DESC, limit input to 5 row(s) per chunk  (cost=641.82 rows=3200) (actual time=193.386..193.388 rows=5 loops=1)
        -> Index range scan on t3 using idx_c2_c3, with index condition: ((t3.c2 = 2) or (t3.c2 = 0))  (actual time=0.348..187.455 rows=3200 loops=1)
 |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.20 sec)
mysql> set polar_optimizer_switch='or_expansion=on';
Query OK, 0 rows affected (0.00 sec)

mysql> desc analyze  select c2 from t3 where (c2 = 2 or c2= 0 )  ORDER BY `t3`.`c3` DESC LIMIT 5;
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                                                                                    |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Limit: 5 row(s)  (actual time=1.249..1.254 rows=5 loops=1)
    -> Sort: derived_1_2.Name_exp_1 DESC, limit input to 5 row(s) per chunk  (actual time=0.104..0.106 rows=5 loops=1)
        -> Table scan on derived_1_2  (actual time=0.006..0.013 rows=10 loops=1)
            -> Union materialize  (actual time=1.246..1.249 rows=5 loops=1)
                -> Limit: 5 row(s)  (actual time=0.336..0.571 rows=5 loops=1)
                    -> Index lookup on t3 using idx_c2_c3 (c2=2; iterate backwards)  (cost=0.00 rows=5) (actual time=0.333..0.566 rows=5 loops=1)
                -> Limit: 5 row(s)  (actual time=0.215..0.431 rows=5 loops=1)
                    -> Index lookup on t3 using idx_c2_c3 (c2=0; iterate backwards)  (cost=0.00 rows=5) (actual time=0.214..0.427 rows=5 loops=1)
 |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.01 sec)

order by因为使用了t3.c3的索引被优化掉了，执行耗时从200ms提升到1ms，查询得到上百倍提升。

规则三：TOP-K类型 IN-LIST子句转换为UNION ALL功能

mysql> set polar_optimizer_switch='or_expansion=off';
Query OK, 0 rows affected (0.00 sec)

mysql> desc analyze  select c2 from t3 where c2 in (2 , 0)  ORDER BY `t3`.`c3` DESC LIMIT 5;
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                                                        |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Limit: 5 row(s)  (actual time=197.497..197.501 rows=5 loops=1)
    -> Sort: t3.c3 DESC, limit input to 5 row(s) per chunk  (cost=641.82 rows=3200) (actual time=197.494..197.496 rows=5 loops=1)
        -> Index range scan on t3 using idx_c2_c3, with index condition: (t3.c2 in (2,0))  (actual time=0.319..191.560 rows=3200 loops=1)
 |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.20 sec)
mysql> set polar_optimizer_switch='or_expansion=on';
mysql> desc analyze  select c2 from t3 where c2 in (2 , 0)  ORDER BY `t3`.`c3` DESC LIMIT 5;
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                                               |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Limit: 5 row(s)  (actual time=1.256..1.260 rows=5 loops=1)
    -> Sort: derived_1_2.Name_exp_1 DESC, limit input to 5 row(s) per chunk  (actual time=0.090..0.093 rows=5 loops=1)
        -> Table scan on derived_1_2  (actual time=0.005..0.012 rows=10 loops=1)
            -> Union materialize  (actual time=1.252..1.255 rows=5 loops=1)
                -> Limit: 5 row(s)  (actual time=0.259..0.545 rows=5 loops=1)
                    -> Index lookup on t3 using idx_c2_c3 (c2=2; iterate backwards)  (cost=0.00 rows=5) (actual time=0.256..0.540 rows=5 loops=1)
                -> Limit: 5 row(s)  (actual time=0.237..0.455 rows=5 loops=1)
                    -> Index lookup on t3 using idx_c2_c3 (c2=0; iterate backwards)  (cost=0.00 rows=5) (actual time=0.236..0.451 rows=5 loops=1)
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)

使用HINT

使用HINT功能进行query block级别的功能控制。

使用 NO_OR_EXPAND hint强制某个query block禁止该改写

 desc SELECT /*+NO_OR_EXPAND(@subq1) */ * FROM t1 WHERE exists (SELECT /*+ QB_NAME(subq1) */  1 FROM t3  WHERE (t1.a = 1 or t1.b = 2) and t3.c1 < 5 and t1.b = t3.c1);
+----+-------------+-------+------------+------+---------------+--------+---------+------------+------+----------+-----------------------------+
| id | select_type | table | partitions | type | possible_keys | key    | key_len | ref        | rows | filtered | Extra                       |
+----+-------------+-------+------------+------+---------------+--------+---------+------------+------+----------+-----------------------------+
|  1 | SIMPLE      | t1    | NULL       | ALL  | idx_a         | NULL   | NULL    | NULL       |  640 |    19.00 | Using where                 |
|  1 | SIMPLE      | t3    | NULL       | ref  | idx_c1        | idx_c1 | 4       | test2.t1.b |   64 |   100.00 | Using index; FirstMatch(t1) |
+----+-------------+-------+------------+------+---------------+--------+---------+------------+------+----------+-----------------------------+

使用OR_EXPAND hint强制某个query block改写成union all

mysql> desc SELECT /*+OR_EXPAND(@subq1) */ * FROM t1 WHERE exists (SELECT /*+ QB_NAME(subq1) */  1 FROM t3  WHERE (t3.c1  = 1 or t1.b = 2) and t3.c1 < 5 and t1.b = t3.c1);
+----+--------------------+-------+------------+------+---------------+--------+---------+-------+------+----------+------------------------------------+
| id | select_type        | table | partitions | type | possible_keys | key    | key_len | ref   | rows | filtered | Extra                              |
+----+--------------------+-------+------------+------+---------------+--------+---------+-------+------+----------+------------------------------------+
|  1 | PRIMARY            | t1    | NULL       | ALL  | NULL          | NULL   | NULL    | NULL  |  640 |   100.00 | Using where                        |
|  2 | DEPENDENT SUBQUERY | t3    | NULL       | ref  | idx_c1        | idx_c1 | 4       | const |   64 |   100.00 | Using where; Using index           |
|  3 | DEPENDENT UNION    | t3    | NULL       | ref  | idx_c1        | idx_c1 | 4       | const |   64 |   100.00 | Using index condition; Using index |
+----+--------------------+-------+------------+------+---------------+--------+---------+-------+------+----------+------------------------------------+

如果where有多个or表达式，使用OR_EXPAND(`query_block` `idx`)强制某个表达式改成成union all

其中idx是该表达式在where表达式中第几个孩子，下标从1开始，示例是将 (t3.c2= 1 or t1.b = 2) 展开成union all了。

mysql> desc format=tree SELECT /*+OR_EXPAND(@subq1 3) */ * FROM t1 WHERE exists (SELECT /*+ QB_NAME(subq1) */  1 FROM t3  WHERE  (t3.c2 = 999 or t1.b = 999) and t3.c1 < 5 and t1.b = t3.c1 and  (t3.c2= 1 or t1.b = 2));
+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN                                                                                                                             |
+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Filter: exists(select #2)  (cost=64.75 rows=640)
    -> Table scan on t1  (cost=64.75 rows=640)
    -> Select #2 (subquery in condition; dependent)
        -> Limit: 1 row(s)
            -> Append
                -> Stream results
                    -> Filter: (t3.c2 = 1)  (cost=17.45 rows=32)
                        -> Index lookup on t3 using idx_c1 (c1=t1.b), with index condition: ((t1.b = 999) and (t3.c1 < 5))  (cost=17.45 rows=64)
                -> Stream results
                    -> Filter: (t3.c1 = 2)  (cost=0.51 rows=0)
                        -> Index lookup on t3 using idx_c2_c3 (c2=999), with index condition: ((t1.b = 2) and lnnvl((t3.c2 = 1)))  (cost=0.51 rows=1)

改写核心思想

Creates a new derived query block under the parent_lex.
Moves the WHERE and HAVING conditions to the derived block.
Updates name resolution contexts for moved items.
Clones ORDER BY and LIMIT clauses into the derived block.
Replaces expressions in the original block with references to fields in the derived table.
Invokes expand_to_union_all() on the target expression to complete the transformation.

图示

step1

继续做or展开，每个or子条件展开成一个Queryblock ，sel#2为模板克隆出sel#3.

step2

对derived对应的UNIT做resolve
- sel#2 会重新fix_fields，有fixed标记的会跳过，新clone的orderby&limit会进行fix_fields。整体打上prepared标记
- sel#3 全新的QB，整体进行prepare
对derived placeholder创建物化表，物化表为derived_1_2
sel#1 里Item refix到derived_1_2 field上。
整个查询树整体就做完了prepare。
